EX10NCD : 10" 2-WAY HIGH EFFICIENCY LOUDSPEAKER W/BACK MOUNTED COMPRESSION DRIVER TWEETER

Features: 2.5″ (63.5mm) Midrange Voice Coil Neodymium Ring Magnet Assembly Rear Mounted Full Sized Compression Driver IP52 Rated Paper Cone With Treated Cloth Surround Die-Cast Aluminum Basket With Radial Venting 1.4″ (36mm) Polyester Tweeter Diaphragm Wide Dispersion Conical HF Waveguide 12dB Passive Crossover Included Protective Grills Included Specifications: Resonant Frequency (fs) 54.8Hz D.C. Voice Coil Resistance (Re) 3.3Ω Mechanical Quality Factor (Qms) 7.18 Electrical Quality Factor (Qes) 0.41 Total Quality Factor (Qts) 0.39 Compliance Equivalent Volume (Vas) 46.9L Mechanical Compliance (Cms) 0.27 mm/N Nominal Impedance 5.2Ω Power Handling 500 Watts Dynamic Wattage 1000 Watts Sensitivity (1w/1m) 106.1 dB Voice Coil Diameter 2.5″ (63.5mm) Product Manual Product Manual PDF Description Turn up the XPERT-ise with the EX10NCD: Your Sound, Amplified!Meet the XPERT EX10NCD, the 10-inch 2-way high-efficiency loudspeaker that's about to elevate your audio
